Hardware |
|
Standard |
Compliant with ADSL Standard |
|
- Full-rate ANSI T1.413 Issue 2 |
|
- G.dmt (ITU G.992.1) |
|
- G.lite (ITU G.992.2) |
|
- G.hs,Multimode (ITU G.994.1) |
|
Capable of ADSL2 Standard |
|
- G.dmt.bis (ITU G.992.3) |
|
Capable of ADSL2+ Standard |
|
- G.dmt.bisplus (ITU G.992.5) |
|
- Reach Extended ADSL (RE ADSL) |
|
Supports Annex A, M, L |
|
Protocol |
RFC 2364 - PPP over ATM (LLC/VCMUX) |
|
RFC 2516 - PPP over Ethernet (LLC/VCMUX) |
|
RFC 1483 - Classic IP over ATM (LLC/VCMUX) |
|
RFC 2684 - Bridged IP over ATM (LLC/VCMUX) |
|
RFC 2684 - Routed IP over ATM (LLC/VCMUX) |
|
AAL and ATM Support |
Supports up to 8 PVCs |
|
ATM Forum UNI 3.1/4.0 PVC |
|
VC and LLC Multiplexing |
|
Integrated ATM AAL5 support (UBR,CBR,VBR-rt and VBR-nrt) |
|
0~255 VPI plus 1~65535 VCI address range |
|
OAM F4 & F5 Segment end-to-end loop-back, AIS, and RDI OAM cells |
|
Ports |
LAN: 4 x Ethernet (10/100Mbps, auto-negotiation, auto MDI/MDI-X) |
|
WLAN: 1 x 802.11b/g/n Access Point with one 2dBi dipole antenna |
|
WAN: 1 x RJ11 |
|
LED Indicators |
PWR, Link, Data, LAN 1~4, WLAN, WPS |
|
Button |
Reset, WPS, Power |
|
Max. Concurrent Sessions |
2048 |
|
Wireless Standard |
IEEE 802.11b, g and 802.11n |
|
Wireless Frequency |
2.4 to 2.4835GHz (Industrial Scientific Medical Band ) |
|
Wireless Channels |
Maximum 14 Channels, depending on regulatory authorities |
|
Wireless Data Encryption |
64 bit / 128 bit WEP, WPA-PSK / WPA2-PSK and WPS PBC |
|
Wireless Data Rate |
Maximum up to 150 Mbps |
|
IEEE 802.11b: 1/2/5.5/11Mbps |
|
IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps |
|
IEEE 802.11n: 14/29/43/58/87/116/130/144Mps in 20MHz; 30/60/90/120/150Mbps in 40MHz |
|
RF Modulation |
IEEE 802.11b mode: DSSS (CCK,QPSK,BPSK) |
|
IEEE 802.11g mode: OFDM (BPSK,QPSK,16QAM,64QAM) |
|
HT20 and HT40: 64 QAM, 16QAM, QPSK, BPSK |
|
Transmit Power |
IEEE 802.11b: 16.5dBm ± 1.5dBm |
|
IEEE 802.11g: 14dBm ± 1.5dBm |
|
IEEE 802.11n HT20M:13dbm ± 1.5dBm |
|
IEEE 802.11n HT40M: 13dbm ± 1.5dBm |
|
Receiver Sensitivity |
IEEE 802.11b: < -80dBm |
|
IEEE 802.11g: < -68dBm |
|
IEEE 802.11n HT20M: < -64dbm |
|
IEEE 802.11n HT40M: < -61dbm |
|
Software |
|
Protocols/Features |
NAT supports multimedia applications |
|
NAT, Static Routing, and RIPv1/2 |
|
Transparent Bridging |
|
Dynamic Domain Name System (DDNS) |
|
SNTP |
|
DNS relay and IGMP proxy |
|
DMZ and Virtual Server |
|
Quality of Service (QoS) for Traffic Prioritization |
|
TR-069 Ready |
|
UPnP |
|
Security |
PPP over PAP (Password Authentication Protocol, RFC 1334) |
|
PPP over CHAP (Challenge Authentication Protocol, RFC 1994) |
|
DoS Protection |
|
Access Control |
|
ACL (Access Control) |
|
IP / MAC / URL Filter |
|
Stateful Packet Inspection (SPI) Firewall |
|
Password protection for system management |
|
Management |
Web-based configuration |
|
Embedded Telnet server for remote and local management |
|
Firmware upgraded and configuration data upload/download via Web |
|
Support DHCP Server/Client/Relay |
|
Built-in diagnostic tool |
|
TR-069 |
|
Environment Specifications |
|
Dimensions (W x D x H) |
117 x 100 x 25 mm |
|
Power |
12V DC, 0.5A |
|
Temperature and Humidity |
Operating temperature: 0 ~ 50 degrees C |
|
Storage temperature: -10 ~ 70 degrees C |
|
Humidity: 10 ~ 95% non-condensing |
|
Emission |
FCC, CE |
