Hardware Specifications |
|
Copper Ports |
48 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports |
|
SFP / mini-GBIC Slots |
4 100/1000Base-X SFP interfaces |
|
Console |
1 x RJ-45-to-RS-232 serial port(9600, 8, N, 1) |
|
Switch Architecture |
Store-and-forward |
|
Switch Fabric |
104Gbps / non-blocking |
|
Switch Throughput |
77.38Mpps |
|
Address Table |
16K MAC address table with Auto learning function |
|
Share Data Buffer |
1.5Mbytes |
|
Flow Control |
Back pressure for Half-Duplex |
|
IEEE 802.3x Pause Frame for Full-Duplex |
|
Jumbo Frame |
16K bytes |
|
LED |
System: |
|
PWR, SYS |
|
Ports: |
|
TP Port:10/100/1000 Link/Act |
|
SFP Slot: Link/Act |
|
Dimensions (W x D x H) |
440 x 220 x 44 mm, 1U height |
|
Weight |
2825g |
|
Power Consumption |
55 watts / 187.6 BTU (maximum) |
|
Power Requirements |
AC 100~240V, 50/60Hz |
|
Management Function |
|
System Configuration |
Console, Telnet, SSH, Web Browser, SNMP v1, v2c and v3 |
|
Management |
Supports both IPv4 and IPv6 addressing |
|
Supports the user IP security inspection for IPv4 / IPv6 SNMP |
|
Supports MIB and TRAP |
|
Supports IPv4 / IPv6 FTP/TFTP |
|
Supports IPv4 / IPv6 NTP |
|
Supports RMOM 1, 2, 3, 9 four group |
|
Supports the RADIUS authentication for IPv4 / IPv6 telnet user name and password |
|
Supports IPv4 / IPv6 SSH |
|
The right configuration for users to adopt radius server’s shell management |
|
Supports CLI, Console, Telnet |
|
Supports SNMPv1 / v2c / v3 |
|
Supports Security IP safety net management function: avoid unlawful landing at nonrestrictive area |
|
Supports Syslog server for IPv4 and IPv6 |
|
Supports TACACS+ |
|
Layer3 Function |
|
Static Route |
Supports maximum 128 static routes |
|
Layer2 Function |
|
Port Configuration |
Port disable/enable |
|
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection |
|
Flow Control disable / enable |
|
Bandwidth control on each port |
|
Port Loopback detect |
|
Port Status |
Display each port’s speed duplex mode, link status, flow control status, and |
|
auto negotiation status |
|
VLAN |
802.1Q Tagged Based VLAN, up to 256 VLAN groups |
|
Q-in-Q |
|
GVRP for VLAN Management |
|
Private VLAN Edge (PVE) supported |
|
Protocol-based VLAN |
|
MAC-based VLAN |
|
IP Subnet VLAN |
|
Bandwidth Control |
TX / RX / Both |
|
Link Aggregation |
IEEE 802.3ad LACP / Static Trunk |
|
Supports 32 groups of 8-Port trunk |
|
QoS |
8 priority queues on all switch ports |
|
Supports strict priority and Weighted Round Robin (WRR) CoS policies |
|
Traffic classification: |
|
■ IEEE 802.1p CoS / ToS |
|
■ IPv4 / IPv6 DSCP |
|
■ Port-based WRR |
|
Multicast |
IGMP v1/ v2 / v3 Snooping |
|
Querier mode support |
|
MLDv1 / v2, MLD v1 / v2 Snooping |
|
Querier mode support |
|
Multicast VLAN Register (MVR) |
|
Access Control List |
Supports Standard and Expanded ACL |
|
IP-based ACL / MAC-based ACL |
|
Time-based ACL |
|
Up to 512 entries |
|
Bandwidth Control |
At least 64Kbps step |
|
Security |
Supports MAC + port binding |
|
IPv4 / IPv6 + MAC + port binding |
|
IPv4 / IPv6 + port binding |
|
Supports MAC filter |
|
ARP Scanning Prevention |
|
Authentication |
IEEE 802.1x port-based network access control |
|
AAA Authentication: TACACS+ and IPv4/IPv6 over RADIUS |
|
SNMP MIBs |
RFC-1213 MIB-II |
|
RFC-1215 Internet Engineering Task Force |
|
RFC-1271 RMON |
|
RFC-1354 IP-Forwarding MIB |
|
RFC-1493 Bridge MIB |
|
RFC-1643 Ether-like MIB |
|
RFC -1907 SNMP v2 |
|
RFC-2011 IP/ICMP MIB |
|
RFC-2012 TCP MIB |
|
RFC-2013 UDP MIB |
|
RFC-2096 IP forward MIB |
|
RFC-2233 if MIB |
|
RFC-2452 TCP6 MIB |
|
RFC-2454 UDP6 MIB |
|
RFC-2465 IPv6 MIB |
|
RFC-2466 ICMP6 MIB |
|
RFC-2573 SNMPV3 notify |
|
RFC-2574 SNMPV3 vacm |
|
RFC-2674 Bridge MIB Extensions (IEEE 802.1Q MIB) |
|
RFC-2674 Bridge MIB Extensions (IEEE 802.1P MIB) |
|
Standard Conformance |
|
Regulation Compliance |
FCC Part 15 Class A, CE |
|
Standards Compliance |
IEEE 802.3 10Base-T |
|
IEEE 802.3u 100Base-TX |
|
IEEE 802.3z Gigabit SX/LX |
|
IEEE 802.3ab Gigabit 1000T |
|
IEEE 802.3x Flow Control and Back pressure |
|
IEEE 802.3ad Port trunk with LACP |
|
IEEE 802.1D Spanning tree protocol |
|
IEEE 802.1w Rapid spanning tree protocol |
|
IEEE 802.1s Multiple spanning tree protocol |
|
IEEE 802.1p Class of service |
|
IEEE 802.1Q VLAN Tagging |
|
IEEE 802.1x Port Authentication Network Control |
|
Environment |
|
Operating |
Temperature: 0 ~ 50 degrees C |
|
Relative Humidity: 5 ~ 95 % (non-condensing) |
|
Storage |
Temperature: -10 ~ 70 degrees C |
|
Relative Humidity: 5 ~ 95 % (non-condensing) |
